MU5502 2WD
- Home
- MU5502 2WD
Kubota MU5502 is equipped with advanced technology ECDIS – 4 valve engine which provides unmatched performance with fuel efficiency. The unique balance shaft technology reduces engine vibration and provides a smoother operation for long working hours without fatigue to the operator
E-CDIS TECHNOLOGY
e-CDIS Technology Engine
Thanks to Kubota’s world renowned expertise in making E-CDIS technology, it delivers the most powerful and effective combustion and lesser fuel consumption. Version of DI engine is most advanced engine, the fuel injecting nozzles are located vertically compared to other tractors that come with inclined nozzles.
4 VALVES SYSTEM
4 Valves System
The 4 valve technology, 2 valves for air suction and 2 valves for exhaust, provides better and cleaner combustion and more power.
BALANCER SHAFT
Balancer Shaft
Kubota's unique balancer shaft on both sides of the engine, Which rotates the twice of the engine speed, opposite to each other and absorbs the vibration created by the engine so efficiently, that it hardly vibrates or makes any noise. As a result, farmers enjoy smoother operations for long hours without fatigue, plus reduced maintenance.
SYNCHRO GEAR
Synchro Gear Transmission
The 12 forward and 4 reverse speed allows MU5502 customers a varied choice of speed options ideal for all types of implements and soil conditions. MU5502 is suitable for all agri as well as commercial applications like Plough, Harrow, TOT, supper seeder, etc.
DUAL ACTING POWER STEERING
Dual Acting Power Steering
The turning performance of the double acting power steering is so smooth that it can be operated even with a single finger.
Engine Power
36.5 kW Cat. (55 HP Cat.)
Valve
4 Valve System
Rear Tyre Size
16.9 x 28 Inch
KUBOTA MU5502-2WD
No. of Cylinders
4
Lift Capacity
1800 Kg
Transmission Type
12F + 4R Gear Shift
OTHER SPECIFICATIONS
| Category | Specification |
|---|---|
| Transmission | |
| Clutch | Double |
| Fuel Tank | |
| Fuel Tank Capacity | 65 litres |
| Brake Types | |
| Brakes | Oil immersed disc |
| Steering Type | |
| Steering | Hydraulic Double acting power steering |
| PTO Type | |
| PTO | Standard 540 |
| Tyres | |
| Front Tyre Size | (19.05 cm x 40.64 cm) 7.5 inch x16 inch |
| Rear Tyre Size | (40.64 cm x 71.12 cm) 16.9 inch x 28 inch |
| Axle Type | |
| Front Axle Type | 2WD |
| Dimension | |
| Overall Width | 1965 mm |
| Overall Length | 3720 mm |
| Total Weight | 2310 Kg |
| Ground Clearance | 420 mm |
| Wheel Base | 2100 mm |
